Raw Edge V Belt

The belt body adopts high-quality synthetic neoprene imported from Japan, and is equipped with a variety of rubber accessories for different purposes; the skeleton material is high-quality polyester hard cord; the belt back is attached with different kinds of cloth for protection.
Compared with the cloth-covered V-belt, the cutting V-belt has a bottom tooth shape that can reduce heat accumulation or stress concentration, extend the life of the belt, and only slightly change when running at high speed.
The combined V-belt has good integrity, and each belt has uniform force, stable operation, high load-bearing transmission force, and it is not easy to shake and turn the belt during use. It is suitable for occasions with pulsating load and shock and vibration, especially for parallel shaft transmission on high and straight ground.

Unit: (mm) model Top width  Section width Belt high angle Ordinary V belt AND 6 5.3 4 40 With 10 8.5 6 40 A 13 11 8 40 B 17 14 11 40 C 22 19 14 40 D 32 27 19 40 AND 38 32 23 40 Narrow V-belt License plate 10 8 8 40 SPA 13 11 10 40 SPB 17 14 14 40 SPC 22 19 18 40 3V (9N) 9.5 8.5 8 40 5V(15N) 16 14.3 13.5 40 8V(25N) 25.4 23.7 23 40

Note: When customers order V-belts, as long as they provide the specifications and models or samples of the V-belts, our company can guarantee to provide them.

1) During the installation and use of the product, the belt must not be scratched, and no chemicals (especially strong oxidizing acids) are allowed. Try to avoid long-term contact with oil and water, so as not to affect the service life of the product.
2) When replacing the product, the tension of the belt must be minimized before it can be taken out. It is strictly forbidden to use non-professional tools to pry it off under high tension.
