Single Sided Synchronous Belt

The belt body is made of high-quality synthetic neoprene imported from Japan, hydrogenated nitrile rubber and mixed with various rubber accessories for different purposes; the frame material is high-quality high-strength glass fiber cord imported from Japan; the toothed surface is specially treated with nylon 66 high elasticity Cloth for protection.

Synchronous belt uses belt teeth to mesh with pulley teeth to transmit power, which is a new type of synchronous transmission. Moreover, the product does not require lubrication, no slip, no pollution, and low noise; the transmission efficiency is more than 98%, the speed ratio range can reach 1:10, the allowable linear speed can reach 50m/s, and the transmission rate ranges from hundreds of watts to several Hundred kilowatts, also suitable for multi-shaft transmission.

The product has good dynamic performance and anti-cracking performance, excellent ozone performance, and also has the characteristics of aging resistance, heat resistance, and abrasion resistance.

、

1) When purchasing, pay attention to the clean and tidy surface of the product, the belt should not be twisted, and the teeth of the belt should be full.
2) During the transportation and installation of the product, it is strictly forbidden to bend, otherwise it will damage the frame material (glass fiber) and affect the strength of the belt.
3) During the installation and use of the product, the belt must not be scratched, and no chemicals (especially strong oxidizing acids) are allowed. Try to avoid long-term contact with oil and water, so as not to affect the service life of the product.
4) When replacing the product, the tension of the belt must be minimized before it can be taken out. It is strictly forbidden to use non-professional tools to pry it off under high pressure.
